We, Saffron Steel & Engineering., are manufacturer and supplier of Tubes. With a wide range of Tubes, we are offering a variety of materials and grades. Our aim is not only to provide products nut also to complete complex operations efficiently with our precise products. We ensure to give every product with the same excellence and quality. A213 GR T1, T2, T5, T11, T22 and T91 Tubes are one of the types of Tubes which are available in our inventory.
Saffron Steel & Engineering. carries a wide range of Inconel 600 compression tube fittings in a variety of Tube OD, size, wall thickness, maximum working pressures and temperatures for compression fittings on pneumatic applications to meet your project’s .
We are supplying this type of Tubes which are enduring, sturdy, and robust. They are suitable in various critical industrial applications as well as operations. We select superior quality raw material by testing it rigorously to provide the highest quality. This type of Tubes are also available in customized configurations. This helps to suit them in different requirements of the clients. As we are using contemporary technology and methods, A 213 GR T1, T2, T5, T11, T22 and T91 Tubes comes with accuracy and excellent surface finishing.
Saffron Steel & Engineering. is taking constant efforts to acquire new skills and enhance production. This is the secret of our success and impeccable quality. Our A 213 GR T1, T2, T5, T11, T22 and T91 Tubes are demanded from domestic as well as international clients. Hence, we follow all industrial as well as international standards while manufacturing Tubes. Our highly precise and durable A 213 GR T1, T2, T5, T11, T22 and T91 Tubes are satisfying the needs of various industries and also help them to enhance the speed of operations.
ASTM A213/ASME SA213 GR T1, T2, T5, T11, T22 & T91 Alloy Steel Tube Specifications
Tube Specification : ASTM A213 / ASME SA213
Size Range : 1/2″ OD up to 5″ OD, customs diameter also available
Outer Diameter :28mm-168mm
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Wall Thickness : 2mm-30mm
Length: : 2m-12m or as required
Form : Round Tube, Square Tube, Rectangular Tube
Alloy Steel Tube Grade : T1, T2, T5 , T9, T11, T12, T22, T91, T92
ASTM A213 Grade T1, T2,T5,T11,T22 & T91 Tubes Equivalent Grades
| STANDARD |
WERKSTOFF NR. |
UNS |
TRADE NAME |
| Alloy Steel T5 |
1.7362 |
K41545 |
5Cr-1/2Mo |
| Alloy Steel T9 |
1.7386 |
S50400 |
9Cr-1Mo |
| Alloy Steel T11 |
1.7338 |
K11597 |
10CrMo5-5 |
| Alloy Steel T12 |
1.7335 |
K11562 |
13CrMo4-5 |
| Alloy Steel T22 |
1.7380 |
K21590 |
10CrMo9-10 |
| Alloy Steel T91 |
1.4903 |
K91560 |
X10CrMoVNb9-1 |
Excellent quality, better surface finish, longer tool life, less heat build-up, suitability for cavities, and inserts are the key features which we are providing with A 213 GR T1, T2, T5, T11, T22 and T91 Tubes. Our highly equipped and experienced team of professionals helps to meet customers ever growing quality as well as service expectation. Every Pipe which we deliver is testes with many quality tests. With different inspections and packaging types, we are providing convenient doorstep service to our esteem clients. We are here to serve excellence by following deadlines and at a reasonable cost.
ASTM A213 Gr. T1, T2,T5,T11, T22 & T91 Tubes Types
Alloy Steel ASTM A213 T1 Seamless Tubes
Alloy Steel ASTM A213 T2 Seamless Tubes
ASTM A213 Alloy Steel T5 Seamless Tubes
ASTM A213 T11 Seamless Tubes
Alloy Steel ASTM A213 T22 Seamless Tubes
ASTM A213 T91 Seamless Tubes
ASTM A213 Alloy Steel Seamless Tubing
Alloy Steel ASTM A213 T1 Boiler Tubes
Alloy Steel ASTM A213 T2 Boiler Tubes
Alloy Steel ASTM A213 T5 Boiler Tubes
Alloy Steel ASTM A213 T11 Boiler Tubes
Alloy Steel ASTM A213 T22 Boiler Tubes
Alloy Steel ASTM A213 T91 Boiler Tubes
ASTM A213 Alloy Steel Boiler Tubing
Alloy Steel ASTM A213 T1 Superheater Tubes
Alloy Steel ASTM A213 T2 Superheater Tubes
Alloy Steel ASTM A213 T5 Superheater Tubes
Alloy Steel ASTM A213 T11 Superheater Tubes
ASTM A213 T22 Superheater Tubes
AS ASTM A213 T91 Superheater Tubes
ASTM A213 Alloy Steel Superheater Tubing
Alloy Steel ASTM A213 T1 Heat-Exchanger Tubes
CrMo ASTM A213 T2 Heat-Exchanger Tubes
ASTM A213 T5 Heat Exchanger Tubes
ASTM A213 T11 Heat Exchanger Tubes
Alloy Steel ASTM A213 T22 Heat-Exchanger Tubes
Alloy Steel ASTM A213 T91 Heat Exchanger Tubes
ASTM A213 Alloy Steel Heat-Exchanger Tubing
Alloy Steel ASTM A213 Tube Tolerances
ASTM A213 / A213M Alloy Steel Tube Outside Diameter Tolerance:
Method |
Outside Diameter, mm |
Tolerance, mm |
Hot Rolled |
OD=101.6 |
+0.4 / -0.8 |
101.6<OD=190.5 |
+0.4 / -1.2 |
190.5<OD=228.6 |
+0.4 / -1.6 |
Cold Drawn |
OD<25.4 |
±0.10 |
25.4=OD=38.1 |
±0.15 |
38.1<OD<50.8 |
±0.20 |
50.8=OD<63.5 |
±0.25 |
63.5=OD<76.2 |
±0.30 |
76.2=OD=101.6 |
±0.38 |
101.6<OD=190.5 |
?0.38 / -0.64 |
190.5<OD=228.6 |
?0.38 / -1.14 |
ASTM A213 / ASME SA 213 Alloy Steel Tube Wall Thickness Tolerance :
Method |
Outside Diameter, mm |
Tolerance, % |
Hot Rolled |
OD=101.6,WT=2.4 |
+40 / -0 |
OD=101.6,2.4<WT=3.8 |
+35 / -0 |
OD=101.6,3.8<WT=4.6 |
+33 / -0 |
OD=101.6,WT>4.6 |
+28 / -0 |
OD>101.6,2.4<WT=3.8 |
+35 / -0 |
OD>101.6,3.8<WT=4.6 |
+33 / -0 |
OD>101.6,WT>4.6 |
+28 / -0 |
Cold Drawn |
OD=38.1 |
+20 / -0 |
OD>38.1 |
+22 / -0 |
ASME SA 213 Grade GR T1, T2, T5, T11, T22 & T91 Tubing Chemical Composition
Grade |
C |
Mn |
P |
S |
Si |
Cr |
Mo |
V |
N |
Ni |
Al |
Nb |
W |
T2 |
0.10-0.20 |
0.30-0.61 |
0.025 max |
0.025 max |
0.10-0.30 |
0.50-0.81 |
0.44-0.65 |
|
|
|
|
|
|
T5 |
0.15 max |
0.30-0.60 |
0.025 max |
0.025 max |
0.50 max |
4.00-6.00 |
0.45-0.65 |
|
|
|
|
|
|
T9 |
0.15 max |
0.30-0.60 |
0.025 max |
0.025 max |
0.25-1.00 |
8.0-10.0 |
0.90-1.10 |
|
|
|
|
|
|
T11 |
0.15 max |
0.30-0.60 |
0.025 max |
0.025 max |
0.50-1.00 |
1.00-1.50 |
0.44-0.65 |
|
|
|
|
|
|
T12 |
0.15 max |
0.30-0.60 |
0.025 max |
0.025 max |
0.50-1.00 |
1.00-1.50 |
0.44-0.65 |
|
|
|
|
|
|
T22 |
0.05-0.15 |
0.30-0.60 |
0.025 max |
0.025 max |
0.50 max |
1.90-2.60 |
0.87-1.13 |
|
|
|
|
|
|
T91 |
0.08-0.12 |
0.30-0.60 |
0.020 max |
0.010 max |
0.20-0.50 |
8.00-9.50 |
0.85-1.05 |
0.18-0.25 |
0.03-0.07 |
0.40 max |
0.04 max |
0.06-0.10 |
|
T92 |
0.07-0.13 |
0.30-0.60 |
0.020 max |
0.010 max |
0.50 max |
8.50-9.50 |
0.30-0.60 |
.015-0.25 |
0.03-0.07 |
0.40 max |
0.04 max |
0.04-0.09 |
1.50-2.0 |
A 213 GR T1, T2, T5, T11, T22 & T91 Tubes Mechanical Properties
Grade |
Tensile Strength, Mpa |
Yield Strength, Mpa |
Elongation, % |
Hardness, HB |
T2 |
415 min |
205 min |
30 min |
163 max |
T5 |
415 min |
205 min |
30 min |
163 max |
T9 |
415 min |
205 min |
30 min |
179 max |
T11 |
415 min |
205 min |
30 min |
179 max |
T12 |
415 min |
205 min |
30 min |
179 max |
T22 |
415 min |
205 min |
30 min |
163 max |
T91 |
585 min |
415 min |
20 min |
250 max |
T92 |
585 min |
415 min |
20 min |
250 max |
ASTM A213/ ASME SA213 Alloy Steel Tubes Application Industries
- Textile machinery
- Oil and gas industry
- Pulp and paper industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
