The Hastelloy c276 is one of the most versatile corrosion-resistant alloys. It is a superalloy of nickel-molybdenum-chromium in addition to tungsten. It offers satisfactory resistance in chemical processing environments such as hot contaminated organic and inorganic media, formic and acetic acids, seawater, chlorine, ferric and cupric chlorides, and many more. The Hastelloy c276 is also suitable in environments such as pollution control and municipal waste treatment and recovery of sour natural gas.
Saffron Steel & Engineering. is a leading manufacturer and supplier of a premium range of Hastelloy c276 Pipes. The high nickel and molybdenum contents make these Pipes exceptionally resistant to crevice corrosion and pitting. Chromium provides resistance from oxidizing media. These Pipes work efficiently even in reducing and wide range of severe environments. We have a team of experienced professionals who manufacture Hastelloy c276 Pipes in customized size, grades, thickness, and specifications as per the customer’s need.
Saffron Steel & Engineering. carries a wide range of Hastelloy C276 pipe and tubes in a variety of lengths, ODs, IDs, size and wall thicknesses to meet your project’s needs—including pipe in dimension as per ASTM and weight-kg. per mtr. (ASME / ANSI B36.19) / weight & thickness of C276 Hastelloy gauge pipes .
We develop superior Hastelloy c276 Pipes having numerous features such as resistance to corrosion cracking, smooth finish, high tensile strength, excellent machinability, and weldability, etc. We use superior quality material to manufacture the Hastelloy c276 Pipes to ensure low maintenance, high corrosion performance, and long service life. We have a highly developed manufacturing unit with the latest machinery to manufacture Hastelloy c276 Pipes, which are best in industry. The Hastelloy c276 Pipes undergo strict supervision at every stage of processing and testing to ensure they are dimensionally accurate and error-free. We design the products by following all the industrial specifications and standards to offer reliable products to our valued customers. We use standard quality material to fabricate efficient Hastelloy c276 Pipes and deliver them at a reasonable price.
Hastelloy C276 Pipe Specifications
Pipe Specification : ASTM B622, B619 / ASME SB622, SB619
Dimension Standard : ANSI B36.19M, ANSI B36.10
Hastelloy C276 Pipe Size : 1/4" sch 10 to 16" sch 80
Hastelloy C276 Tube Size : OD 1/16"~4", Wall: 0.010"~0.250", Length: 17'/24' FT R/L
Outside Diameter : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Hastelloy C276 Pipes Equivalent Grades
| STANDARD |
UNS |
WNR. |
EN |
JIS |
OR |
GOST |
| Hastelloy C276 |
N10276 |
2.4819 |
NiMo16Cr15W |
NW 0276 |
ЭП760 |
ХН65МВУ |
Saffron Steel & Engineering. develops high-grade Hastelloy c276 Pipes, which are particularly useful for numerous applications such as Pharmaceuticals, Gas Processing, Sea Water Equipment, Heat Exchangers, Pulp and Paper Industry, Oil Refineries, condensers and many more. We provide proper and safe packaging options to ensure that there is no damage to the products during delivery and transportation. We satisfy our esteem customers by ensuring on-time delivery and doorstep service as per their requirements.
Hastelloy C276 Pipe & Tube Types
Hastelloy Alloy C276 Seamless Pipe
ASME SB622 Hastelloy C276® Seamless Pipes
Nickel Alloy UNS N10276 Seamless Pipe
Hastelloy 2.4819 Seamless Pipe
Hastelloy Alloy C276 Welded Pipe
ASME SB619 Hastelloy C276® Welded Pipes
Nickel Alloy UNS N10276 Welded Pipe
Hastelloy 2.4819 Welded Pipe
Hastelloy Alloy C276 Seamless Tubes
ASTM B622 Hastelloy C276® Seamless Tube
Nickel Alloy UNS N10276 Seamless Tube
Hastelloy C276 Seamless Tubing
Hastelloy Alloy C276 Welded Tube
ASTM B626/ASME SB626 Hastelloy C276 Welded Tubes
Nickel Alloy UNS N10276 Welded Tubes
Hastelloy C276 Welded Tubing
Hastelloy C276 Pipes & Tubes Dimensions:
All Pipes is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
| Pipe/Tube |
NB Sizes |
Sch 5 |
Sch 10 |
Sch 40 |
Sch 80 |
Sch 160 |
| Hastelloy C276 Pipes |
1/8″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
1/4″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
3/8″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
1/2″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
3/4″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
1″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
1 1/4″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
1 1/2″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
2″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
2 1/2″ |
|
|
|
|
|
| Hastelloy C276 Seamless Pipes |
3″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
4″ |
|
|
|
|
|
| Hastelloy C276 Seamless Pipes |
5″ |
|
|
|
|
|
| Hastelloy C276 Pipes |
6″ |
|
|
|
|
|
Hastelloy C276 Pipes Chemical Composition
| Grade |
Ni |
C |
Mo |
Mn |
Si |
Fe |
P |
S |
Co |
Cr |
W |
V |
| Hastelloy C276 |
Balance |
0.01 max |
15–17 |
1.0 max |
0.08 max |
4–7 |
0.04 max |
0.03 max |
2.5 max |
14.5–16.5 |
3–4.5 |
0.35 max |
Hastelloy C276 Pipes Mechanical Properties
| Grade |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| Hastelloy C276 |
8.89 g/cm3 |
1370 °C (2500 °F) |
Psi – 1,15,000 , MPa – 790 |
Psi – 52,000 , MPa – 355 |
40 % |
Hastelloy® C276 Pipes Application Industries
- Textile machinery
- Oil and gas industry
- Pulp and paper industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
