Monel 400 is a combination of nickel and copper, which has excellent strength and corrosion resistance properties. It is available in multiple forms for various products in a wide range of temperatures. It is extensively suitable for piping applications as it has anti-corrosive properties and provides resistance to both seawater and steam.
Saffron Steel & Engineering. is a leading supplier and exporter of a wide range of Monel 400 Pipes, which is perfect for areas where corrosion resistance is of the highest priority. It is reliable for both acidic and alkaline environments. We fabricate the best quality Monel 400 Pipes having beneficial properties such as high mechanical strength, excellent weldability, good ductility, high toughness, and high corrosion resistance. Monel 400 Pipes has It provides resistance to pitting and crevice corrosion cracking even under extreme conditions. We have a highly qualified professional team that designs Monel 400 Pipes using supreme materials in compliance with international excellence standards. We offer premium quality efficient Monel 400 Pipes at most affordable rates.
Saffron Steel & Engineering. carries a wide range of Monel 400 pipe and tubes in a variety of lengths, ODs, IDs, size and wall thicknesses to meet your project’s needs—including pipe in dimension as per ASTM and weight-kg. per mtr. (ASME / ANSI B36.19) / weight & thickness of 400 Monel gauge pipes .
We offer the most durable Monel 400 Pipes in different sizes, shapes, and thicknesses. They are available in various dimensions and materials. We manufacture Monel 400 Pipes in high-grade material to ensure higher efficiency and long service life. We follow all the international specifications and standards to ensure Monel 400 Pipes have enhanced high dimensional accuracy, high strength, and durability. We ensure that all our products go through strict quality tests under the supervision of our experienced quality team before dispatching them to our customers. We have a highly equipped development unit having the latest machinery and equipment. We keep on upgrading our products and service to meet our esteem customer’s requirements and as per market demands.
Monel 400 Pipe Specifications
Pipe Specification : ASTM B165, B725 / ASME SB165, SB725
Dimension Standard : ANSI B36.19M, ANSI B36.10
Monel 400 Pipe Size : 1/4" sch 10 to 16" sch 80
Monel 400 Tube Size : OD 1/16"~4", Wall: 0.010"~0.250", Length: 17'/24' FT R/L
Outside Diameter : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Monel 400 Pipes Equivalent Grades
| STANDARD |
UNS |
WNR. |
AFNOR |
EN |
JIS |
BS |
GOST |
| Monel 400 |
N04400 |
2.4360 |
NU-30M |
NiCu30Fe |
NW 4400 |
NA 13 |
МНЖМц 28-2,5-1,5 |
Saffron Steel & Engineering. manufactures superior Monel 400 Pipes, which are reliable for applications such as Pet rochemicals, Gas industries, Power Generation, Seawater treatment plant, Pharmaceutical industries, Pulp, and Paper industries, Heat Exchangers, and many more. We maintain our storage and warehousing facilities to ensure the on-time delivery of products in case of urgent requirements. We offer numerous choices for packaging and shipping, depending on the location and the needs of our customers.
Monel 400 Pipe & Tube Types
Monel Alloy 400 Seamless Pipe
ASME SB165 Monel 400® Seamless Pipes
Nickel Alloy UNS N04400 Seamless Pipe
Monel 2.4360 Seamless Pipe
Monel Alloy 400 Welded Pipe
ASME SB725 Monel 400® Welded Pipes
Nickel Alloy UNS N04400 Welded Pipe
Monel 2.4360 Welded Pipe
Monel Alloy 400 Seamless Tubes
ASTM B165 Monel 400® Seamless Tube
Nickel Alloy UNS N04400 Seamless Tube
Monel 400 Seamless Tubing
Monel Alloy 400 Welded Tube
ASTM B730/ASME SB730 Monel 400 Welded Tubes
Nickel Alloy UNS N04400 Welded Tubes
Monel 400 Welded Tubing
Monel 400 Pipes & Tubes Dimensions:
All Pipes is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
| Pipe/Tube |
NB Sizes |
Sch 5 |
Sch 10 |
Sch 40 |
Sch 80 |
Sch 160 |
| Monel 400 Pipes |
1/8″ |
|
|
|
|
|
| Monel 400 Pipes |
1/4″ |
|
|
|
|
|
| Monel 400 Pipes |
3/8″ |
|
|
|
|
|
| Monel 400 Pipes |
1/2″ |
|
|
|
|
|
| Monel 400 Pipes |
3/4″ |
|
|
|
|
|
| Monel 400 Pipes |
1″ |
|
|
|
|
|
| Monel 400 Pipes |
1 1/4″ |
|
|
|
|
|
| Monel 400 Pipes |
1 1/2″ |
|
|
|
|
|
| Monel 400 Pipes |
2″ |
|
|
|
|
|
| Monel 400 Pipes |
2 1/2″ |
|
|
|
|
|
| Monel 400 Seamless Pipes |
3″ |
|
|
|
|
|
| Monel 400 Pipes |
4″ |
|
|
|
|
|
| Monel 400 Seamless Pipes |
5″ |
|
|
|
|
|
| Monel 400 Pipes |
6″ |
|
|
|
|
|
Monel 400 Pipes Chemical Composition
| Grade |
Ni |
C |
Al |
Mn |
Si |
Fe |
Cu |
S |
| Monel 400 |
63.0 min |
0.3 max |
0.50 max |
2.0 max |
0.5 max |
1.0 - 2.5 |
28.0 - 34.0 |
0.02 max |
Monel 400 Pipes Mechanical Properties
| Density |
Melting Point |
Yield Strength (0.2%Offset) |
Tensile Strength |
Elongation |
| 8.8 g/cm3 |
1350 °C (2460 °F) |
Psi – 35,000 , MPa – 240 |
Psi – 80,000 , MPa – 550 |
40 % |
Monel® 400 Pipes Application Industries
- Textile machinery
- Oil and gas industry
- Pulp and paper industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
