Hastelloy C276 is an alloy that contains Nickel, Molybdenum, Chromium with additional Tungsten, which has excellent corrosion resistance in various severe environments. This alloy has a very high resistance to crevice corrosion, cracking, pitting, general corrosion and chloride stress corrosion. Hastelloy C276 is also performed well in high-temperature industrial applications. It is suitable in environments like formic acid, acetic acid, seawater, acetic acids, cupric chlorides, chlorine dioxide, chlorine, hypochlorite and ferric chlorides.
Saffron Steel & Engineering., are manufacturers and suppliers of Hastelloy C276 products. By considering the needs of clients, we are manufacturing Compression Tube Fittings in Hastelloy c276. These Hastelloy c276 Compression Tube Fittings are one of the demanded products from our inventory. We are offering all necessary products or various components that are required to complete industrial applications. Our leak-tight, as well as gas-tight Hastelloy Compression Fittings, are easy to install, assemble, disassemble, and reassemble.
Saffron Steel & Engineering. carries a wide range of Hastelloy C276 compression tube fittings in a variety of Tube OD, size, wall thickness, maximum working pressures and temperatures for compression fittings on pneumatic applications to meet your project’s .
We are focusing on providing Hastelloy c276 Compression Tube Fittings with excellent quality and benefits. Our Fit-and-Forget principle helps our clients to get satisfying products. We follow all defined quality standards and processes to produce the most precise Hastelloy c276 Compression Tube Fittings. As per the client’s requirements and demands, we are delivering perfectly suitable Fittings to them.
Saffron Steel & Engineering. is offering the highest quality Hastelloy Tube Fittings, which are suitable for various critical industrial applications. We are using the latest technology, modern machinery, and defined methods to produce high-grade Hastelloy Instrumentation Tube Fittings in minimum time. We inspect every individual Fitting rigorously, which helps to maintain the quality standards higher and to deliver excellent quality to our esteem clients.
Hastelloy C276 Tube Fittings Specifications
Size Range : 1/16 in. to 2 in. & 2mm to 50 mm.
End Connection Thread Type : NPT - ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel - ISO 228 | ISO/BSP Tapered - ISO 7, BS EN 10226-1 | SAE (Unified) - ASME B1.1
Dimensional Range : 1/16 to 2 inches (imperial); 2 to 50 mm (metric)
Working Pressures : Upto 2000 to 6000 PSI
Medium-Pressure, Gaugeable : Pressure Ratings: Up to 20 000 psig (1378 bar)
Temperature Ratings: Up to 1000°F (537°C)
High-Pressure : Pressure Ratings: Up to 60 000 psig (4134 bar)
Temperature Ratings: Up to 1000°F (537°C)
Type : Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories
Hastelloy C276 Compression Tube Fittings Equivalent Grades
| STANDARD |
UNS |
WNR. |
EN |
JIS |
OR |
GOST |
| Hastelloy C276 |
N10276 |
2.4819 |
NiMo16Cr15W |
NW 0276 |
ЭП760 |
ХН65МВУ |
These cost-effective Hastelloy c276 Compression Tube Fittings are fulfilling the needs of our clients in different sectors. Our reusable and corrosion-free Hastelloy c276 Instrumentation Tube Fittings are offering zero leakage service in any critical applications and operation. We are producing these Fittings in bulk amount so that we can provide them in the required amount. We are happy to serve excellence to our clients within decided time and at reasonable rates.
Hastelloy C276 Compression Tube Fittings Types
Hastelloy C276 Male Connector
Hastelloy C276 Male Bulk Head Connector
Hastelloy C276 Male Elbow
Hastelloy C276 Male Run Tee
Hastelloy C276 Male Branch Tee
Hastelloy C276 Male Tube Adapter
Hastelloy C276 45 Deg Positionable Male Elbow
Hastelloy C276 Female Connector
Hastelloy C276 Female Bulk Head Connector
Hastelloy C276 Female Elbow
Hastelloy C276 Female Run Tee
Hastelloy C276 Female Branch Tee
Hastelloy C276 Female Tube Adapter
Hastelloy C276 Female Manometer Connector
Hastelloy C276 Union
Hastelloy C276 Reducing Union
Hastelloy C276 Bulk Head Union
Hastelloy C276 Union Elbow
Hastelloy C276 Union Tee
Hastelloy C276 Union Cross
Hastelloy C276 Tube Socket Weld Union
Hastelloy C276 Front Ferrule
Hastelloy C276 Back Ferrule
Hastelloy C276 Tube End Closure
Hastelloy C276 Blanking Plug
Hastelloy C276 Blanking End
Hastelloy Alloy C276 Nut
Hastelloy C276 Coupling Cap (Nuts)
Hastelloy C276 Fitting End Closure
Hastelloy C276 Compression Tube Fittings Dimensions:
OD |
OD Actual |
Thread Designation - Nominal Size |
Thread per inch |
(fraction inch) |
(inches) |
(inches) |
NPT |
BSP |
5/16 |
0.3125 |
1/16 |
27 |
28 |
13/32 |
0.405 |
1/8 |
27 |
28 |
35/64 |
0.540 |
1/4 |
18 |
19 |
43/64 |
0.675 |
3/8 |
18 |
19 |
27/32 |
0.840 |
1/2 |
14 |
14 |
1-3/64 |
1.050 |
3/4 |
14 |
14 |
1-5/16 |
1.315 |
1 |
11-1/2 |
11 |
1-21/32 |
1.660 |
1-1/4 |
11-1/2 |
11 |
1-29/32 |
1.900 |
1-1/2 |
11-1/2 |
11 |
2-3/8 |
2.375 |
2 |
8 |
11 |
2-7/8 |
2.875 |
2-1/2 |
8 |
11 |
3-1/2 |
3.5 |
3 |
8 |
11 |
4 |
4.0 |
3-1/2 |
8 |
11 |
4-1/2 |
4.5 |
4 |
8 |
11 |
5-5/8 |
5.563 |
5 |
8 |
11 |
6-5/8 |
6.625 |
6 |
8 |
11 |
Hastelloy C276 Compression Tube Fittings Chemical Composition
| Grade |
Ni |
C |
Mo |
Mn |
Si |
Fe |
P |
S |
Co |
Cr |
W |
V |
| Hastelloy C276 |
Balance |
0.01 max |
15–17 |
1.0 max |
0.08 max |
4–7 |
0.04 max |
0.03 max |
2.5 max |
14.5–16.5 |
3–4.5 |
0.35 max |
Hastelloy C276 Compression Tube Fittings Mechanical Properties
| Grade |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| Hastelloy C276 |
8.89 g/cm3 |
1370 °C (2500 °F) |
Psi – 1,15,000 , MPa – 790 |
Psi – 52,000 , MPa – 355 |
40 % |
Hastelloy C276 Tube Fittings Application Industries
- Textile machinery
- Oil and gas industry
- Pulp and paper industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
