Saffron Steel & Engineering. is a manufacturer of Pipe Fittings. By considering all needs and demands, we are manufacturing Pipe Fittings in different metals and alloys. Nickel is one of the suitable materials which is utilized in Pipe Fitting manufacturing. Including all other metals and alloys, we are using Nickel to produce high-quality Pipe Fittings. We select materials after rigorous testing and supervision so that we can provide durable and precise Fittings.
We are manufacturing Nickel Pipe Fittings in various shapes, measures, and dimensions. Our Nickel Pipe Fittings offers multiple features like robust construction, durable, high strength, optimum performance, high tensile strength, superior finishing, sturdy construction, dimensionally accurate and particular design. These Nickel Pipe Fittings are suitable for gas as well as fluid carrying. These Pipe Fittings are easy to install, cleaning, resembling, and also require very minimal maintenance.
Saffron Steel & Engineering. carries a wide range of Nickel pipe fittings in a variety of size, wall thicknesses, dimensions and tolerance to meet your project’s needs—including pipe fittings in dimension as per ASME/ANSI B16.9, ASME B16.25, ASME B16.28, ASME B16.49, MSS-SP-43 Fittings / weight & thickness of Nickel pipe fittings.
We are supplying high-grade Nickel Pipe Fittings in a wide variety of dimension and specification. As per the requirements demand of clients, we manufacture custom made Nickel Pipe Fitting with all specifications. We are following all national and international set industry norms to make our Fittings perfectly suitable in any industry.
We have client base within India as well as out of India and hence we also taking care of packing and shipping of Nickel Pipe Fitting. We are using the highest quality material and alloys to manufacturing Nickel Pipe Fitting and also ensuring quality and durability by testing its different features. In the whole manufacturing process, we perform various tests to durability, reliability, strength, toughness, service life, accuracy, hardness, strength, and workability of Nickel Pipe Fitting.
Nickel Pipe Fittings Specifications
Specification : ASTM B366 / ASME SB366
Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings
ASME B16.25 : Buttwelding Ends
ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends
MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
Size Range : ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Seamless Butt Weld Fitting Size : 1/2" - 10"
Welded Butt Weld Fittings Size : 1/2" - 48"
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type : Seamless / Welded / Fabricated
Our leakproof Nickel Pipe Fitting are perfectly suitable for numerous industrial operations. Our Premium quality Nickel Pipe Fittings are helping to complete various critical activities efficiently. Our skilled professionals are taking care of the quality and workability of Fittings by strict examination as well as supervision. By choosing the proper material for packing and fastest way for shipping, we ensure on-time delivery of Nickel Pipe Fitting. We are happy to serve excellence with our high-grade products at reasonable rates along with convenient doorstep service.
Nickel Pipe Fittings Types
Nickel Elbow
ASTM B366 Nickel 90° Elbow
ASME SB366 Nickel 45° Elbow
ANSI B16.9 Nickel 180° Elbow
Nickel Long Radius - LR Elbow
Nickel Short Radius - SR Elbow
Nickel Tee
ASTM B366 Nickel Buttweld Tee
Nickel Alloy Equal Tee
ASME SB366 Nickel Unequal Tee
ANSI B16.9 Nickel Alloy Pipe Tee
Nickel Straight Tees
Nickel Short Stub End
ASTM B366 Nickel Short Stub End
ASME SB366 Nickel Short Stub End
Nickel Alloy Short Stub End
ASME / ANSI B16.9 Nickel Short Stub End
Nickel Long Stub End
ASTM B366 Nickel Long Stub End
ASME SB366 Nickel Long Stub End
Nickel Alloy Long Stub End
ASME / ANSI B16.9 Nickel Long Stub End
Nickel Eccentric Reducer
ASTM B366 Nickel Eccentric Reducer
ASME SB366 Nickel Eccentric Reducer
Nickel Alloy Eccentric Reducer
ASME / ANSI B16.9 Nickel Eccentric Reducer
Nickel Concentric Reducer
ASTM B366 Nickel Concentric Reducer
ASME SB366 Nickel Concentric Reducer
nconel Alloy Concentric Reducer
Nickel ASME / ANSI B16.9 Concentric Reducer
Nickel Buttweld Cap
ASTM B366 Nickel Caps
Nickel Alloy Pipe Cap
Nickel Alloy End Cap
Nickel Pipe End Cap
ANSI B16.9 Nickel End Pipe Cap
Nickel Cross
ASTM B366 Nickel Cross
Nickel Buttweld Cross
Nickel Reducing Cross
ANSI B16.9 Nickel Alloy Unequal Cross
ASME SB366 Nickel Equal Cross
Nickel Pipe Fittings Dimensions :
| Nominal Pipe Size |
All Fittings |
All Fittings |
All Fittings |
Elbows/ Tees |
180° Return Bends |
180° Return Bends |
180 Deg Return Bends |
Reducers |
Caps |
| NPS |
O.D. at Bevel (1), (2) |
I.D. at End
(1), (3), (4)
|
Wall Thickness (3) |
Centre-to-End Dimension A,B,C,M |
Centre-to-Centre O |
Back-to-Face K |
Alignment of Ends U |
Overall Length H |
Overall Length E |
| ½ to 2½ |
0.06
-0.03
|
0.03 |
Not less than 87.5% of nominal thickness |
0.06 |
0.25 |
0.25 |
0.03 |
0.06 |
0.12 |
| 3 to 3 ½ |
0.06 |
0.06 |
Not less than 87.5% of nominal thickness |
0.06 |
0.25 |
0.25 |
0.03 |
0.06 |
0.12 |
| 4 |
0.06 |
0.06 |
Not less than 87.5% of nominal thickness |
0.06 |
0.25 |
0.25 |
0.03 |
0.06 |
0.12 |
| 5 to 8 |
0.09
-0.06
|
0.06 |
Not less than 87.5% of nominal thickness |
0.06 |
0.25 |
0.25 |
0.03 |
0.06 |
0.25 |
| 10 to 18 |
0.16
-0.12
|
0.12 |
Not less than 87.5% of nominal thickness |
0.09 |
0.38 |
0.25 |
0.06 |
0.09 |
0.25 |
| 20 to 24 |
0.25
-0.19
|
0.19 |
Not less than 87.5% of nominal thickness |
0.09 |
0.38 |
0.25 |
0.06 |
0.09 |
0.25 |
| 26 to 30 |
0.25
-0.19
|
0.19 |
Not less than 87.5% of nominal thickness |
0.12 |
… |
… |
… |
0.19 |
0.38 |
| 32 to 48 |
0.25
-0.19
|
0.19 |
Not less than 87.5% of nominal thickness |
0.19 |
… |
… |
… |
0.19 |
0.38 |
Nickel Pipe Fittings Application Industries
- Textile machinery
- Oil and gas industry
- Pulp and paper industry
- Power plants
- Energy industries
- Furniture
- Pharmaceutical processing industry
- Modern architecture
- Home appliances
- Water waste projects
- Synthetic fiber
- Heat exchanger
- Fluid piping
- Dairy and food processing
