Other Availability Incoloy Grades Pipes - In stock
Table Of Content
Incoloy 800 Pipe is a combination of nickel and chromium. Incoloy 800H and 800HT alloy are part of the Incoloy 800 series. Incoloy 800H is a combination of nickel, chromium, and iron, and 800HT is a configuration derivative of 800H alloy. Incoloy 800HT Pipes are ideally suitable for creep-resistant applications as it offers superior resistance. It has the combined properties of thermal and mechanical processing of the alloy and resistance to prolonged exposure to elevated temperatures.
Saffron Steel & Engineering. is a leading manufacturer, exporter, and supplier of a qualitative range of Incoloy 800/800H/800HT Pipes, which are available in different sizes, specifications, and thicknesses as per our esteem customer’s requirements. We assemble these Incoloy 800/800H/800HT pipes by following the national and international industrial specifications and quality standards. We ensure to provide Incoloy 800/ 800H/ 800HT Pipes with excellent tensile strength and significant resistance to oxidation as well as carburization properties. Incoloy 800/800H/800HT Pipes are widely useful in applications such as nuclear power plants, chemical and petrochemical processing, heat-treating equipment, paper pulp industry, heat exchangers, and other piping systems where resistance to chloride stress-corrosion cracking is required.
Pipe Specification : ASTM B407, B514 / ASME SB407, SB514
Dimension Standard : ANSI B36.19M, ANSI B36.10
Incoloy 800/H/HT Pipe Size : 1/4" sch 10 to 16" sch 80
Incoloy 800/H/HT Tube Size : OD 1/16"~4", Wall: 0.010"~0.250", Length: 17'/24' FT R/L
Outside Diameter : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
Incoloy 800 | N08800 | 1.4876 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800 | NA 15 | ЭИ670 | XH32T |
Incoloy 800H | N08810 | 1.4958 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800H | NA 15(H) | ЭИ670 | XH32T |
Incoloy 800HT | N08811 | 1.4959 | - | X8NiCrAlTi32-21 | NCF 800HT | NA 15(HT) | ЭИ670 | XH32T |
We offer Incoloy 800/ 800H /800HT Pipes with outstanding benefits and features such as high-temperature strength, resistance to oxidation and carburization, high creep rupture strength, corrosion resistance to acidic, and sulphur-containing atmospheres. We use superior quality materials to fabricate Incoloy 800/800H/800HT Pipes to ensure their long service life. These pipes maintain their excellent chemical properties, even in high-temperature and pressure applications. We have a highly equipped processing unit to manufacture a wide range of Incoloy 800/ 800H/ 800HT Pipes, which are suitable for transferring liquid and other fluids to several industries. They have good machinability and have excellent weld-ability characteristics. We strictly conduct numerous tests for checking the entire manufacturing process in the unit under the inspection of our experts. We have a team of highly qualified professionals having years of experience in different industrial sectors who manufacture premium quality Incoloy 800 /800H/800HT Pipes. We offer standard packaging and shipping options at reasonable rates for Incoloy 800 /800H/800HT Pipes to ensure safe, on-time, and doorstep delivery as per the customer’s demands.
Incoloy 800HT Seamless Pipe
ASME SB407 Incoloy 800® Seamless Pipes
Nickel Alloy UNS N08800 Seamless Pipe
Incoloy 1.4876 Seamless Pipe
Incoloy Alloy 800 Welded Pipe
ASME SB514 Incoloy 800® Welded Pipes
Nickel Alloy UNS N08810 Welded Pipe
Incoloy 1.4959 Welded Pipe
Incoloy Alloy 800H Seamless Tubes
ASTM B407 Incoloy 800® Seamless Tube
Nickel Alloy UNS N08800 Seamless Tube
Incoloy 800HT Seamless Tubing
Incoloy Alloy 800HT Welded Tube
ASTM B515/ASME S B515 Incoloy 800 Welded Tubes
Nickel Alloy UNS N08800 Welded Tubes
Incoloy 800H Welded Tubing
All Pipes is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.
Pipe/Tube | NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
---|---|---|---|---|---|---|
Incoloy 800 Pipes | 1/8″ | |||||
Incoloy 800 Pipes | 1/4″ | |||||
Incoloy 800H Pipes | 3/8″ | |||||
Incoloy 800HT Pipes | 1/2″ | |||||
Incoloy 800 Pipes | 3/4″ | |||||
Incoloy 800 Pipes | 1″ | |||||
Incoloy 800H Pipes | 1 1/4″ | |||||
Incoloy 800 Pipes | 1 1/2″ | |||||
Incoloy 800HT Pipes | 2″ | |||||
Incoloy 800 Pipes | 2 1/2″ | |||||
Incoloy 800 Seamless Pipes | 3″ | |||||
Incoloy 800 Pipes | 4″ | |||||
Incoloy 800 Seamless Pipes | 5″ | |||||
Incoloy 800 Pipes | 6″ |
Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
Incoloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .1 max | 1.5 max | .015 max | 1.0 max |
Incoloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .05-.10 max | 1.5 max | .015 max | 1.0 max |
Incoloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .25-.60 | .85-1.20 | .06-.10 max | 1.5 max | .015 max | 1.0 max |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
7.94 g/cm3 | 1350-1400 ℃ | Psi - 75,000 , MPa -520 | Psi - 30,000 , MPa - 205 | 30 - 35 % |
